The rectifier is the perfect candidate for this job in industries & Home to convert AC into DC.
Equipment: Oscilloscope Function Generator Digital Multimeter Diode (1N4007) Resistors (1kΩ) Discussion: Rectification: Rectification is the process of conversion of the alternating current In electronics, Rectifier circuit is the most used circuit because almost every electronic appliance operates on DC (Direct Current) but the availability of the DC Sources are limited such as electrical outlets in our homes provide AC (Alternating current). To study the application of diode in digital logic gates.
Diode Rectifiers Objectives: To observe the working of Half Wave Rectifiers.
